MTP®/APC-MTP®/APC Female to Female Fiber Optic Patch Cord SM 100/400G 12/24 Cores PVC/LSZH Yellow Trunk cable
Product
MTP®/APC-MTP®/APC Female to Female 10/40G SM 12/24 Fibers 3M PVC/LSZH Yellow Trunk cable
1,Adopting imported grinding equipment and materials, advanced production technology ensures more stable transmission;
2,All components have been optically tested and are in line with RoHS standards;
3,Conformity with ANSI/TIA/EIA;ISO/IEC, GR and other international standards, requirements for durability, moisture resistance, coupling stress, optical fiber tensile force and adaptability to harsh environment such as humidity, extreme temperature, plug and pull force and cable tension force, impact and vibration;
4,Simple push-pull locking structure, convenient and intuitive insertion and removal, suitable for different installation environment;
5,adapt to the working temperature (-40℃~+75℃), storage temperature (-40℃~+85℃)
Application Environment
Product
Application Environment
MTP®/APC-MTP®/APC Female to Female 10/40G SM 12/24 Fibers 3M PVC/LSZH Yellow Trunk cable
Application of MPO/MTP Fiber Optic Patch Cord parallel optical link between PC card and chassis panel, link between O/E modules, optical switch frame link, gigabit Ethernet, cable TV, video, active device or transceiver interface, building cabling, telecommunication network, multimedia, industrial and military applications, etc.
Specifications
Product
Specifications
MTP®/APC-MTP®/APC Female to Female 10/40G SM 12/24 Fibers 3M PVC/LSZH Yellow Trunk cable
Type Performance | Singlemode | Multimode | |||||||||||
| UPC | APC | UPC | |||||||||||
| Insertion loss | The maximum | ≤0.3daB | ≤0.3dB | ≤0.3dB | |||||||||
| Typical values | 0.2 dB | 0.2dB | 0.2dB | ||||||||||
| Return loss | ≥50 dB ≥55 dB | ≥35dB | |||||||||||
| Test the wavelength | 1310nm & 1550nm | 850nm&1300nm | |||||||||||
| Mechanical properties (500 cycles) | ΔIL＜0.1dB | ||||||||||||
