Adtek’s MTP®/MPO Pre-terminated Multi-core Fiber Optic Patch Cord support direct connections between the distribution frame and equipment.It has an MTP® connector at one end and a simplex or duplex universal connector (LC, SC, etc.) at the other end.
Adtek’s MTP®/MPO Pre-terminated Multi-core Fiber Optic Patch Cord support direct connections between the distribution frame and equipment.It has an MTP® connector at one end and a simplex or duplex universal connector (LC, SC, etc.) at the other end.
ADTEK recruitment丨New Year talent, rabbit with good luck Shenzhen ADTEK Technology Co., Ltd was established in 2007, which is a national high-tech enterprise integrating R&D, production, operation and service. As a leading ODM manufacturer and exporter of fiber optic communication devices, Advent has over 14 years of export
Application of MPO/MTP®-LC Fiber Optic Patch Cord parallel optical link between PC card and chassis panel, link between O/E modules, optical switch frame link, gigabit Ethernet, cable TV, video, active device or transceiver interface, building cabling, telecommunication network, multimedia, industrial & military applications, etc.
Type Performance | Singlemode | Multimode | |||||||||||||
| APC Standard Loss | APC Low Loss | PC Standard Loss | PC Low Loss | ||||||||||||
Insertion loss | The maximum | ≤0.7dB | ≤0.35dB | ≤0.5dB | ≤0.35dB | ||||||||||
| Typical values | 0.4dB | 0.2dB | 0.35dB | 0.2dB | |||||||||||
| Return loss | ≥60 dB | ≥35dB | |||||||||||||
| Test Wavelength | 1310nm & 1550nm | 850nm&1300nm | |||||||||||||
