Introduction

With the rapid adoption of 5G and artificial intelligence, the optical communications industry is undergoing significant advancements. As data center network speeds continue to escalate—from 400G to 800G, 1.6T, and potentially up to 3.2T—there is a pressing need for technological innovation and industry upgrades.

What is LPO Technology?

LPO (Linear-Drive Pluggable Optics) optical

 modules utilize linear drive technology to enhance data transmission efficiency while lowering power consumption and cost. By eliminating DSP (Digital Signal Processing), LPO modules simplify design and are ideal for short-distance, high-bandwidth, low-power, and low-latency data communication needs.

The LPO module operates as follows:

• Transmission Side: Digital signals are converted into analog signals via a Digital-to-Analog Converter (DAC).
• Reception Side: Analog signals are converted back into digital signals using an Analog-to-Digital Converter (ADC).

Key electronic components in LPO modules include DSP, laser drivers (LDD), transimpedance amplifiers (TIA), limiting amplifiers (LA), and Clock and Data Recovery (CDR) chips.

LPO vs. CPO: A Comparative Analysis

LPO and CPO (Co-Packaged Optics) represent two advanced optical technologies, each with distinct characteristics:

1. Integration Approach

• CPO: Integrates optical devices (such as lasers, modulators, and receivers) directly with the chip in a compact package. This allows for high integration of optical and chip components.
• LPO: Uses laser processing to form optical devices directly on the silicon wafer, integrating optical components with silicon chips.

2. Design Flexibility

• CPO: Provides greater design flexibility, facilitating customization and configuration during the packaging stage.
• LPO: Offers less flexibility as optical devices are formed directly on the silicon wafer, limiting customization options.

3. Application Scenarios

• CPO: Suited for data centers and high-performance computing environments requiring high density and low power consumption.
• LPO: Ideal for applications needing optical integration on silicon chips, such as sensors and LiDAR (Light Detection and Ranging).

LPO modules excel in power consumption, cost, latency, and maintenance compared to traditional optical modules. They are a practical evolution of pluggable optical modules, especially for the 800G era.

Current Challenges and Future Prospects

Despite its potential, LPO technology is still in its early stages of standardization and may face interoperability issues. Effective implementation requires advanced technical capabilities, including design specifications, solution development, and extensive integration testing.

ADTEK has proactively invested in R&D, offering a range of short-fiber components compatible with LPO modules. These components are designed to enhance data transmission efficiency and stability while providing flexible solutions for transmission rates ranging from 40G to 800G.

Conclusion

The advancement of LPO technology marks a significant breakthrough in optical module technology. Addressing key concerns such as power efficiency, cost-effectiveness, low latency, and ease of maintenance, LPO modules are ideal for enhancing the performance of optical communication systems.

According to the latest report by QYResearch, titled “Global LPO Optical Module Market Report 2023-2029,” the global LPO optical module market is expected to reach $680 million by 2029, with a compound annual growth rate (CAGR) of 27.0%. As the AIGC (Artificial Intelligence Generated Content) wave progresses, data center optical networks are rapidly advancing towards 800G, ushering in the golden age of LPO technology.
