Cat8 Ethernet Bulk Cables are the latest generation of double shielded (SFTP) copper cables that support bandwidths of up to 2000 MHz and transmission rates of up to 40 Gbps. In addition, Cat8 cables are upwardly compatible with all RJ45 cables, and are specifically designed for 25/40GBASE-T applications. Due to its short transmission distance characteristic of only 30m, it is particularly suitable for connecting servers, switches, patch panels and other equipment in short-distance data centers.
Cat8 Ethernet Bulk Cables are the latest generation of double shielded (SFTP) copper cables that support bandwidths of up to 2000 MHz and transmission rates of up to 40 Gbps. In addition, Cat8 cables are upwardly compatible with all RJ45 cables, and are specifically designed for 25/40GBASE-T applications. Due to its short transmission distance characteristic of only 30m, it is particularly suitable for connecting servers, switches, patch panels and other equipment in short-distance data centers.
Unlock Unprecedented Performance and Efficiency with MTP & MPO Connector Assemblies In today’s data-driven world, where speed, density, and reliability are paramount, traditional fiber optic cabling solutions can quickly become bottlenecks. Enter MTP and MPO connector assemblies – the advanced, high-performance solution designed to revolutionize your network infrastructure. Built for the
Cat8 Ethernet Bulk Cables are commonly used for home network cabling, enterprise network cabling, video surveillance system cabling and telephone system cabling, etc. It also supports PoE and is suitable for wireless access points, IP cameras and other devices.
| Product Type | Category | Conductor Type | Shielding Type | Wire Gauge(±0.008mm) | O.D.(±0.3mm) | |||
| Cat8 | Solid | S/FTP | 22AWG(1/0.64) | 8.4 | ||||
| Stranded | S/FTP | 24AWG(7/0.2) | 8.0 | |||||
| Wring Scheme | T568A/T568B | |||||||
| Conductor Material | Pure Bare Copper | |||||||
| Sheath Material | PVC、LSZH | |||||||
| Electrical Characteristics | Max. DC Resistance 20℃ | Ω/km | 66Ω | |||||
| Max. DC Conductor Resistance Unbalance | % | 2.5 | ||||||
| Mutual Capacitance | nF/100m | 5.6 | ||||||
| Characteristic Impedance(1-2000MHz) | Ω | 100±15% | ||||||
| Bandwidth | MHz | 2000 | ||||||
| Data Rate Support | Gbps | 25/40 | ||||||
| Operating Temperature | –20°C~ +60°C(-4~140℉) | |||||||
| Physical Properties | Insulation | Tensile Strength(before aging) | Kgf/mm² | >1.68 | ||||
| Elongation(before aging) | % | >300 | ||||||
| Sheath | Tensile Strength(before aging) | Kgf/mm² | >1.41 | |||||
| Elongation(before aging) | % | >100 | ||||||
| Others | Conductor Resistance 20℃ | Ω/km | <93.8 | |||||
| Insulation Shrinkback | 121℃x1hr | |||||||
| Insulation Cold Bend | -20℃x4hr | |||||||
| Sheath Cold Bend | -20℃x4hr | |||||||
