CAT6 Shielded FTP Network Patch Cord 26AWG PVC/LSZH
Product
CAT6 Shielded FTP Network Patch Cord 24AWG PVC/LSZH
- Support T568A(ISDN) and T568B (ALT) pin configuration;
- RJ45 crystal oboe surface strolling gold, ensure very good contact and signal transmission performance;
- Made by injection molding process, the wire is sealed and does not oxidize;
- 100% factory test, can ensure the performance;
- Meet the international standards ANSI/TIA/EIA-568B, IEC61156-5 5E and EN50288-2-1 and TIA-568-C.2 and domestic standards YD/T1019-2013.
Application Environment
Product
Application Environment
CAT6 Shielded FTP Network Patch Cord 24AWG PVC/LSZH
The 1M CAT6 FTP network patch cord 36AWG purple PVC/LSZH is widely used in data center, network cabinet, office connection network transmission equipment, such as POE switch, computer, etc.It is the best choice for designing, deploying, and maintaining an efficient and flexible data environment.
Specifications
Product
Specifications
CAT6 Shielded FTP Network Patch Cord 24AWG PVC/LSZH
| Connector Type | RJ-45 |
| Conductor | 26AWG,Oxygen-free pure copper wire |
| Electrical characteristics | 1. Maximum conductor resistance@20°C：66Ω/km； 2. Maximum unbalance resistance@20°C：2.5%； 3. Mutual capacitance：5.6nF/100m； 4. The characteristic impedance：100±15%Ω（1 到 100MHZ）； 5. The band width：100MHz。 |
| Skin material options | PVC、LSZH |
| Operating temperature | -20°C 至 + 60°C（-4~140℉） |
| Safety standards | RoHS，ISO/IEC11801 The requirements for the super five categories |
| Copper outer diameter | 5.8 ± 0.3mm |
