Cat6 Ethernet Bulk Cables offer a notable improvement in transmission performance compared to Cat5e. Cat6 has been further optimized in terms of crosstalk and return loss, building upon the advancements of Cat5e. With a transmission speed reaching up to 10Gbps and a maximum transmission distance of 100m, Cat6 is an ideal solution for network environments with high bandwidth requirements.
Cat6 Ethernet Bulk Cables offer a notable improvement in transmission performance compared to Cat5e. Cat6 has been further optimized in terms of crosstalk and return loss, building upon the advancements of Cat5e. With a transmission speed reaching up to 10Gbps and a maximum transmission distance of 100m, Cat6 is an ideal solution for network environments with high bandwidth requirements.
The Toolless keystone jack, an innovative network connection device, greatly simplifies the traditional network wiring process by allowing users to quickly connect network cables without the punch tool. With the compatibility, it supports multiple categories of network cables, such as Cat 5e, Cat 6, etc., to meet different speed and
Cat6 Ethernet Bulk Cables Ethernet Bulk Cables are commonly used for home network cabling, enterprise network cabling, video surveillance system cabling and telephone system cabling, etc. It also supports PoE and is suitable for wireless access points, IP cameras and other devices.
| Product Type | Category | Conductor Type | Shielding Type | Wire Gauge(±0.008mm) | O.D.(±0.3mm) | |||
| Cat5e | Solid | U/UTP | 23AWG(1/0.57) | 6.3 | ||||
| F/UTP | 23AWG(1/0.57) | 7.2 | ||||||
| SF/UTP | 23AWG(1/0.57) | 7.8 | ||||||
| Stranded | U/UTP | 24AWG(7/0.20 or 0.18) | 6.0 | |||||
| 28AWG(7/0.12) | 3.8 | |||||||
| F/UTP | 26AWG(7/0.16) | 6.0 | ||||||
| SF/UTP | 26AWG(7/0.16) | 6.2 | ||||||
| Wring Scheme | T568A/T568B | |||||||
| Conductor Material | Pure Bare Copper | |||||||
| Sheath Material | PVC、LSZH | |||||||
| Electrical Characteristics | Max. DC Resistance 20℃ | Ω/km | 66Ω | |||||
| Max. DC Conductor Resistance Unbalance | % | 2.5 | ||||||
| Mutual Capacitance | nF/100m | 5.6 | ||||||
| Characteristic Impedance(1-100MHz) | Ω | 100±15%(1到250MHz) | ||||||
| Bandwidth | MHz | 250 | ||||||
| Data Rate Support | Gbps | 1月10日 | ||||||
| Operating Temperature | –20°C~+60°C(-4~140℉) | |||||||
| Physical Properties | Insulation | Tensile Strength(before aging) | Kgf/mm² | >1.68 | ||||
| Elongation(before aging) | % | >300 | ||||||
| Sheath | Tensile Strength(before aging) | Kgf/mm² | >1.41 | |||||
| Elongation(before aging) | % | >100 | ||||||
| Others | Conductor Resistance 20℃ | Ω/km | <93.8 | |||||
| Insulation Shrinkback | 121℃x1hr | |||||||
| Insulation Cold Bend | -20℃x4hr | |||||||
| Sheath Cold Bend | -20℃x4hr | |||||||
