ADTEK specializes in the development and production of 100G 1520-1620nm DWDM dense wavelength division multiplexer modules for DWDM networks. The product design is based on TFF (Thin Film Filter) technology.
ADTEK specializes in the development and production of 100G 1520-1620nm DWDM dense wavelength division multiplexer modules for DWDM networks. The product design is based on TFF (Thin Film Filter) technology.
2022 OFC丨ADTEK new products debut! Meet you at San Diego Convention Center The Optical Fiber Communication Expo and Symposium (OFC) is the highest specification, largest, oldest, most professional and influential international event in the field of optical communication in the world, of which the Optical Fiber Communication Expo is held
ADTEK specializes in the development and production of 100G 1520-1620nm DWDM dense wavelength division multiplexer module/ABC box for long-distance, high-capacity long-distance trunk network, or large-capacity metropolitan network core nodes.
| Parameter | unit | Specifications |
| Port configuration | nm | 1X6 1X12 1X18 |
| Center wavelength | nm | ITU、ITU+1 |
| Channel spacing | nm | 20 |
| Channel bandwidth | nm | λc±6.5 |
| Channel insertion loss | dB | ≤2.0 ≤3.0 ≤3.5 |
| Adjacent channel isolation | dB | ≥30 |
| Non-adjacent channel isolation | dB | ≥40 |
| Polarization dependent loss | dB | ≤0.2 |
| PMD | ps | ≤0.1 |
| Return loss | dB | ≥45 |
| Directional | dB | ≥50 |
| The most powerful | mw | ≤300 |
| Working temperature | ℃ | -5 to 75 |
| Storage temperature | ℃ | -40 to 85 |
| Fiber type | — | G657A1 |
| Package size | mm | Insert box：130x100x24.5/130x100x50 ABS box：80x58x8/100x80x10 LGX box：standard/2 in/4 in 1 19 Inch 1U The case：standard |
